Honda CBR600RR 2009 User Manual

−
−
−
−
〈〉
〈〉
(1)
(1) coolant temperature meter
Centigrade (°C)
Fahrenheit (°F)
26
Coolant Temperature Meter
Gauges, Indicators & Displays
Instruments & Controls
The coolant temperature meter ( ) shows
the coolant temperature digitally.
Temperature Display
USA : Fahrenheit (°F), or
Centigrade (°C).
Canada : Centigrade (°C).
1
‘‘--’’ is displayed.
Actual coolant
temperature is
displayed.
Actual coolant
temperature is
displayed and
flashed.
The display remains
and flashes
‘‘270 °F (132 °C)’’.
Below
94 °F (34 °C)
Between
95 °F 250 °F
(35 °C 121 °C)
Between
251 °F 269 °F
(122 °C 131 °C)
Above
270 °F (132 °C)
０８／０９／１９ ２０：４０：１２ ３１ＭＦＪ６２０ ００３５

Honda CBR600RR 2009 Specifications

General

Engine Type	599cc liquid-cooled inline four-cylinder
Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	12.2:1
Induction	Dual Stage Fuel Injection (DSFI)
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	#525 O-ring-sealed chain
Front Suspension	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.1 inches travel
Front Brake	Dual radial-mounted four-piston calipers with 310mm discs
Rear Brake	Single 220mm disc
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Wheelbase	53.9 inches
Rake	23.5 degrees
Seat Height	32.3 inches
Fuel Capacity	4.8 gallons
Curb Weight	410 pounds
Transmission	Six-speed
Trail	3.8 inches
