Honda cbr650f - Front Wheel

Tyre Puncture u Removing Wheels
88
Troubleshooting
When removing and installing the wheel, be
careful not to damage the wheel speed
sensor and pulser ring.
❙
Front Wheel
Removal
1. Park on a firm, level surface.
2. Cover both sides of the front wheel and
brake calipers with protective tape or cloth.
3. On the left side, remove the mounting
bolts and remove the brake caliper
4. On the right side, remove the mounting
bolts and brake caliper.
u Support the brake caliper assembly so
that it doesn’t hang from the brake
hose. Do not twist the brake hose.
u Avoid getting grease, oil, or dirt on
the disc or pad surfaces.
u Do not pull the brake lever while the
brake caliper is removed.
u Take care to prevent the brake caliper
from scratching the wheel during
removal.
CBR650FA only
Mounting
bolts
Brake caliper
Tape or cloth
Wheel speed sensor
(CBR650FA only)
Pulser ring
(CBR650FA only)
