Tyre Puncture u Removing Wheels
89
continued
Troubleshooting
5. Loosen the right axle pinch bolt.
6. Remove the front axle bolt.
7. Support your motorcycle securely and
raise the front wheel off the ground
using a maintenance stand or a hoist.
8. Loosen the left axle pinch bolt.
9. On the left side, withdraw the front axle
shaft, and remove the side collars and
wheel.
Front axle bolt
Axle pinch bolt
Axle pinch bolt
Front axle shaft
