Honda Click125i 2022 User Manual

When the Idling Stop System Does Not Operate Properly u Engine Does Not Start Even If the Throttle is Opened
99
Troubleshooting
Engine Does Not Start Even If
the Throttle is Opened
Engine does not start even if the throttle is
opened, perform the followings.
While the engine is stopped by the Idling Stop
system, if you operate the side stand, the
flashing Idling Stop indicator turns off or stops
flashing and stays on, and the Idling Stop
system is cancelled. Restart the engine with
the start button, referring to the starting
procedure (
2 P. 43) for standard engine
starting.
While the engine is stopping by the Idling
Stop system, if you press the Idling Stop switch
to IDLING, the Idling Stop system will be
cancelled. Restart the engine with the start
button, referring to the starting procedure
(
2 P. 43) for standard engine starting.
If the Idling Stop indicator flashes (the Idling
Stop switch is at IDLING STOP position), but
engine does not start even if the throttle is
opened, perform the followings.
Check the battery and battery terminals. If the
battery is weak, contact your dealer.
ACB125CBT
If the side stand is down:
If the Idling Stop switch is at IDLING:
Low (or dead) battery or battery lead is loose:
19 ACB125CBT CBF (IN PH) 32K60A100.book Page 99 Monday, April 2, 2018 1:48 PM

Honda Click125i 2022 Specifications

General

Displacement	124.9 cc
Bore x Stroke	52.4 x 57.9 mm
Compression Ratio	11.0:1
Max Torque	10.8 Nm @ 5, 000 rpm
Fuel System	PGM-FI (Programmed Fuel Injection)
Frame Type	Underbone
Front Suspension	Telescopic Fork
Rear Suspension	Unit Swing
Front Brake	Disc
Rear Brake	Drum
Wheelbase	1, 280 mm
Seat Height	769 mm
Ground Clearance	132 mm
Curb Weight	111 kg
Max Power	8.3 kW (11.1 hp) @ 8, 500 rpm
Ignition System	Full transistorized
Starting System	Electric
Transmission	V-Matic
Fuel Tank Capacity	5.5 L
Engine Type	Single-cylinder, 4-stroke, SOHC
Front Tire	80/90-14
Rear Tire	90/90-14
