Honda EU22i User Manual

18
CONTROLS & FEATURES
Overload Alarm (Indicator)
If the generator is overloaded (in excess of 2.2 kVA), or if there is a short
circuit in a connected appliance, the overload indicator (red) will come
ON. The overload indicator (red) will stay ON, and after about four
seconds, current to the connected appliance(s) will shut off, and the
output indicator (green) will go OFF. However, the engine will continue
to run.
If the overload indicator blink continuously,it suggests an abnormal of
inverter unit (see page 64).
Oil Alert Indicator
The Oil Alert
system is designed to prevent engine damage caused by
an insufficient amount of oil in the crankcase. Before the oil level in
the crankcase can fall below a safe limit, the Oil Alert indicator (red)
comes ON and the Oil Alert system automatically will stop the engine
(the engine switch will remain in the ON position).
If the engine stops or the Oil Alert indicator (red) comes ON when you
pull the starter grip, check the engine oil level (see page 48) before
troubleshooting in other areas.
OVERLOAD INDICATOR
(RED)
OIL ALERT INDICATOR
(RED)
32Z446000.book Page 18 Friday, February 2, 2018 3:46 PM

Honda EU22i Specifications

General

Castor wheels	No
Product color	Black, Red
Oil tank capacity	0.44 L
Fuel type	Gasoline
Noise level	53 dB
Rated power	- W
Rated voltage	220 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	- l/h
Rated DC voltage	12 V
Fuel tank capacity	3.6 L
Engine displacement	121 cm³
Output power capacity	1.8 kVA
Output power capacity (max)	2.2 kVA

Weight and Dimensions

Depth	290 mm
Width	509 mm
Height	425 mm
Weight	21100 g
