35
OPERATION
DC RECEPTACLE
BLACK LEAD
RED LEAD
DC CIRCUIT PROTECTOR
BATTERY CHARGING CABLE
(optional equipment)
Connect the red lead of the battery charging cable to the positive
( ) battery terminal and the black lead to the negative ( ) battery
terminal.
Do not start the vehicle while the battery charging cable is connected
and the generator is running. The vehicle or the generator may be
damaged.
Start the generator (see page ).
An overloaded DC circuit, excessive current draw by the battery, or a
wiring problem will trip the DC circuit protector (PUSH button extends
out). If this happens, wait a few minutes before pushing in the circuit
protector to resume operation. If the DC circuit protector continues to
go OFF, discontinue charging and see your authorized Honda
generator dealer. The circuit protector does not prevent overcharging
the battery.
4.
3.
23
