Honda EU3200i User Manual

SERVICING YOUR GENERATOR
59
SPARK ARRESTER SERVICE
The spark arrester must be serviced every 100 hours to keep it functioning as
designed.
If the engine has been running, the muffler will be very hot. Allow the muffler to
cool before servicing the spark arrester.
Clean the spark arrester as follows:
1. Remove the two 6×15 mm screws, and the rear cover.
Remove the two 6 mm screws, two 6×15 mm screws and the muffler
protector.
MUFFLER PROTECTOR
6 mm SCREWS
REAR COVER
6×15 mm SCREWS
6×15 mm SCREWS
6 mm SCREW 6×15 mm SCREW

Honda EU3200i Specifications

General

Model	EU3200i
Category	Portable Generator
Run Time per Tankful at 1/4 Load	8.6 hours
Dry Weight	59.1 lbs
Dimensions	22.5" x 12.0" x 17.8"
Starting Watts	3200W
Running Watts	2600W
Inverter	Yes
Run Time at 1/4 Load	8.6 hours
Starting System	Recoil
Maximum AC Output	3200W
Rated AC Output	2600W
Engine Type	4-stroke
DC Output	12V, 8A
Fuel Tank Capacity	1.2 gallons
Outlets	1x 120V 20A (5-20R), 1x 120V 30A (TT-30R)
