Honda EU70is User Manual

20
CONTROLS & FEATURES
Folding Handle
The foldable handle makes the generator easy to push and should be
folded when the generator is stationary. Do not rest objects on the
extended handle.
To Extend The Handle
Lift handle upward. Lock levers will lock and secure the handle into
place.
To Fold The Handle
1.Press both handle lock levers downward.
2.Lower the handle.
HANDLE
Handle in
pushing
position
Handle in
stationary
position
HANDLE LOCK LEVER
36Z376000.book 20 ページ ２０１４年９月１９日 金曜日 午後６時２６分

Honda EU70is Specifications

General

Model	EU70is
Type	Inverter
Maximum AC Output	7000 VA
Rated AC Output	5500 VA
Engine	GX390
Engine Displacement	389 cc
Fuel Type	Gasoline
Run Time per Tankful	6.5 hours at rated load
Starter System	Electric
DC Output	12V, 8.3A
Run Time at 1/4 Load	18 hours
Noise Level	52 dB(A) at 1/4 load
Rated Voltage	220-240V
