(2)
(1)
(1) A screws (2) B screw
99
Left Side Cover Removal
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
The left side cover must be removed to
service the main fuse.
Removal
(cont’d)
Remove the rear cover (page 98).
Open the seat (page 47).
Remove the A screws (1) and B screw
(2).
1.
2.
3.
82
04/09/27 21:43:26 31MCT630_108

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda FSC600D/A 2005 SILVER WING and is the answer not in the manual?

Honda FSC600D/A 2005 SILVER WING Specifications

General IconGeneral
Displacement582 cc
Bore x Stroke72.0mm x 71.5mm
Fuel SystemPGM-FI electronic fuel injection
TransmissionAutomatic V-Matic belt drive
Front Tire120/80-14
Rear Tire150/70-13
Height1, 430 mm
IgnitionDigital transistorized with electronic advance
Front Suspension41 mm hydraulic fork
Rear SuspensionSwingarm with twin shock absorbers
Front BrakeSingle 276 mm disc with three-piston caliper
Rear BrakeSingle 240mm disc with CBS twin-piston caliper
InductionPGM-FI
