30A
10A, 15A,
30A
10A, 15A
30A
FSC600D:
FSC600A:
main fuse A
main fuse B
other fuses
183
If a Fuse Blows
Taking Care of the Unexpected
All of the electrical circuits on your
scooter have fuses to protect them from
damage caused by excess current flow
(short circuit or overload).
If something electrical on your scooter
stops working, the first thing you should
check for is a blown fuse.
Determine from the chart on the circuit
fuse box cover which fuse or fuses control
that component. Check those fuses first,
but check all the fuses before looking
elsewhere for another possible cause of
the problem. Replace any blown fuses and
check component operation.
(cont’d)
The main fuse A (and spare) is located
on the starter motor magnetic switch
inside the left side cover.
The main fuse B and circuit fuse boxes
(including spare fuses) are located
under the seat.
A spare circuit fuse is located in the
fuse box.
Recommended Fuses
To prevent an accidental short circuit,
turn the ignition switch OFF before
checking or replacing the fuses.
1.
04/09/27 21:54:10 31MCT630_192

Honda FSC600D/A 2005 SILVER WING Specifications

General

Displacement	582 cc
Bore x Stroke	72.0mm x 71.5mm
Fuel System	PGM-FI electronic fuel injection
Transmission	Automatic V-Matic belt drive
Front Tire	120/80-14
Rear Tire	150/70-13
Height	1, 430 mm
Ignition	Digital transistorized with electronic advance
Front Suspension	41 mm hydraulic fork
Rear Suspension	Swingarm with twin shock absorbers
Front Brake	Single 276 mm disc with three-piston caliper
Rear Brake	Single 240mm disc with CBS twin-piston caliper
Induction	PGM-FI
