Honda GCV135E User Manual

1
OWNER’S MANUAL
SERIAL NUMBER AND ENGINE TYPE
GCV135E·GCV160E
Honda Motor Co., Ltd. 2007
32Z0M604
00X32-Z0M-6040
08/05/21 13:01:00 32Z0M600_001

Honda GCV135E Specifications

General

Displacement	135 cc
Compression Ratio	8.0 : 1
Fuel Type	Unleaded gasoline
Fuel System	Carburetor
Cooling System	Air-cooled
Ignition System	Transistorized Magneto
Starting System	Recoil Starter
Lubrication System	Splash lubrication
Net Power Output	3.5 hp (2.6 kW) at 3, 600 rpm
Max Power Output	3.0 kW (4.0 HP) at 3, 600 rpm
Fuel Tank Capacity	0.9 L
Engine Type	4-stroke, single cylinder, overhead valve (OHV)
Net Torque	8.7 Nm (6.4 lb-ft) at 2, 500 rpm

Summary

Safety Instructions

General Safe Operation Guidelines

Provides essential safety practices for operating the engine, covering ventilation, fire hazards, user safety, and refueling.

Specific Safety Precautions and Warnings

Details specific safety warnings related to fuel spills, exhaust gases, hot components, and indicates the location and meaning of safety signals.

Starting the Engine

Manual Choke Starting Procedure

Step-by-step guide for starting the engine using manual choke, including fuel valve and control lever adjustments.

Starting with Flywheel Brake Lever

Instructions for starting engines equipped with a flywheel brake lever, detailing lever operation and starter grip use.

Automatic Choke Starting Procedures

Outlines starting procedures for engines with automatic return choke and manual choke lever types.

Automatic Choke Type Starting

Steps for starting engines with an automatic choke, covering fuel valve, control lever, and starter grip actions.

Stopping the Engine

Stopping Manual Throttle Types

Procedures for stopping the engine on manual throttle models by moving the control lever to SLOW.

Stopping with Flywheel Brake Lever

Stopping Without Flywheel Brake Lever

Troubleshooting

Engine Starting Issues Diagnosis
