Honda GX270 User Manual

8
CONTROLS & FEATURES
CONTROLS
Fuel Valve Lever
OONN
OOFFFF
FUEL VALVE LEVER
The fuel valve opens and closes the passage between the fuel tank
and the carburetor.
The fuel valve lever must be in the ON position for the engine to run.
When the engine is not in use, leave the fuel valve lever in the OFF
position to prevent carburetor flooding and to reduce the possibility of
fuel leakage.
03/08/21 20:07:18 31ZH9613_009

Honda GX270 Specifications

General

Engine Type	Air-cooled 4-stroke OHV
Bore x Stroke	77 mm x 58 mm
Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Oil Capacity	1.1 L (1.2 US qt)
Ignition System	Transistorized Magneto Ignition
Fuel System	Carburetor
Lubrication System	Splash
Displacement	270 cm3
Net Power Output	6.3 kW (8.4 HP) @ 3, 600 rpm
Starting System	Recoil start
Dry Weight	25.0 kg (55.1 lbs)
Fuel Tank Capacity	5.3 liters
