SERVICE INFORMATION
LUBRICATION & SEAL POINTS
Material Location Remarks
Engine oil Crankshaft pin and gear teeth
Piston outer surface, ring groove and piston pin hole
Piston pin outer surface
Piston ring entire surface
Cylinder inner surface
Connecting rod big and small end bearing
Connecting rod bolt threads and seating surface
Cam pulley cam lobe, journal and decompressor area
Cam pulley shaft sliding surface
Valve stem sliding surface and stem end
Valve stem seal lips
Valve spring entire surface
Valve adjusting screw threads
Valve adjusting lock nut threads and seating surface
Rocker arm pivot and slipper surface
Rocker arm shaft entire surface
Timing belt entire surface
Flywheel nut threads and seating surface
Governor weight holder gear
Governor holder shaft journal
Governor arm shaft journal
Each oil seal outer surface
Multi-purpose grease Each O-ring entire surface
Each oil seal lips
Control lever sliding surface
Recoil starter case reel sliding surface
Recoil starter ratchet sliding surface
Recoil starter ratchet guide inside
Threebond® 1207B Head cover mating surface
Cylinder barrel mating surface
Breather pipe See page 14-4
