2-7
dummyheaddummyhead
SERVICE INFORMATION
OIL LEVEL
SWITCH CORD
OIL LEVEL
SWITCH PLUG
ENGINE
STOP CORD
OIL ALERT
UNIT PLUG
OIL ALERT
UNIT CORD
OIL LEVEL
SWITCH CORD
Y
YBl
BlBu
to IGNITION COIL
to OIL LEVEL SWITCH
OIL ALERT
UNIT
OIL LEVEL
SWITCH CORD
0 – 20°
10 – 15 mm
