6-2
MUFFLER HRN216
1. REMOVAL/INSTALLATION
 CAUTION
The engine and muffler become very hot during operation, and
they remain hot for a while after operation.
A hot engine or muffler can burn you.
Be sure that the engine is cold before muffler removal/installation.
12 N•m (9 ft-lb)
6 x 23 mm BOLT (3)
MUFFLER
MUFFLER GASKET
[optional part]
MUFFLER PROTECTOR
6 x 79 mm BOLT (CT bolt*) (2)
4 x 6 mm SCREW
[optional part]
· Use a plastic hammer to loosen carbon deposits
from the muffler, and then remove carbon deposits
from muffler.
· If the seal flange is dented or damaged, replace the
muffler.
· Check the cylinder barrel exhaust port for damage.
· Do not tap on the muffler seal flange and do not
damage this part.
MUFFLER SEAL
FLANGE
EXHAUST PORT
SPARK ARRESTER [optional part]
INSTALLATION:
Install after removing the carbon from the
screen with a wire brush.
Inspect for tears or damage.
* CT indicates a self-tapping bolt

Honda HRN216 Series Specifications

General

Cutting Width	21 inches
Deck Material	Steel
Mulching Capability	Yes
Bag Capacity	2.5 bushels
Starting System	Recoil
Bagging Capability	Yes
Side Discharge Capability	Yes
Wheel Size	8-inch front, 8-inch rear
Drive Type	Variable Speed
