PARTS AND CONTROLS INITIAL SNOW THROWER
SETUP
Tools Required
12 mm wrench, 10 mm wrench, and a Phillips screwdriver (AM type
only)
List of Loose Parts
With help from an assistant, carefully remove the snow thrower and
loose parts from the carton and compare the loose parts against the
following list. Contact the authorized Honda dealer from whom you
purchased the snow thrower if any of the loose parts shown are not
included with your snow thrower.
CHUTE GUIDE
CONTROL
(A, AS type)
FUEL CAP
AUGER
CLUTCH
LEVER
SPARK PLUG
COVER
(A, AM type)
OIL FILLER CAP
ENGINE OIL
DRAIN PLUG
(AS
type)
CHUTE TURN
CONTROL
(A, AS type)
ELECTRIC START
BUTTON (AS type)
CHUTE HANDLE
(AM type)
Ref.
No.
Description Qty.

Chute guide and handle (AM type only) 1

6 mm flange bolt (AM type only) 3

6 mm self-locking nut (AM type only) 3

Key (AS type only) 2

Honda Genuine oil (16 oz) 1

Owner’s Manual 1





