99
Digital TachometerOIL PRESSURE INDICATOR
GOES OFF AND ENGINE
SPEED IS LIMITED
TAKING CARE OF UNEXPECTED PROBLEMS
(GREEN)
(GREEN)
BUZZER
BUZZER
Side-Mount Type
Panel-Mount/Top-Mount Types
If the throttle is closed suddenly after
full throttle operation, engine speed
may drop below the specified idle
rpm, and that could activate the
engine protection system
momentarily.
If the engine protection system
remains activated after 30 seconds,
return to the nearest boat landing, and
have the outboard motor inspected by
an authorized Honda Marine dealer.
If low oil pressure activates the
engine protection system, stop the
engine, check the engine oil level
(p. ), and add oil if needed.
If oil pressure becomes low, the oil
pressure indicator will go off, and the
engine protection system limits
engine speed. If you are at cruising
speed, engine speed will decrease
automatically.
The oil pressure indicator is also
equipped with a buzzer that sounds
when the oil pressure indicator goes
off.
Low oil pressure may be the result of
a low engine oil level, or there may
be a problem with the engine
lubrication system.
With the engine oil at the
recommended level, restart the
engine. If the lubrication system is
OK, the oil pressure indicator should
come on within 30 seconds, and the
engine will respond normally to
throttle control lever operation.
Normal
Abnormal
69
