10 A, 30 A
97
BATTERY WILL NOT
CHARGE AND ELECTRIC
STARTER WILL NOT
OPERATE
Fuse Replacement
TAKING CARE OF UNEXPECTED PROBLEMS
Main Fuse
Never use a f use with a rating
greater than specif ied. Serious
damage to the electrical system could
result.
Disconnect the battery cable at the
battery negative ( ) terminal bef ore
replacing the f use.
Failure to do so may cause a short
circuit.
The battery-charging (ACG) circuit
and the electric starter relay circuit
are protected by the 10 and 30-
ampere main fuses and 90-ampere
ACG fuse. If a fuse burns out, the
engine will not charge the battery,
and the electric starter will not
operate.
The ignition switch is protected by
the 10-ampere main fuse. If the fuse
burns out, the engine will not start or
run, and the power trim/tilt switch
will not operate.
MAIN FUSE RATINGS:
Stop the engine and disconnect the
battery cable.
Remove the engine cover.
Remove the fuse covers.
Remove and inspect the fuses. If a
fuse is burnt out, install a
replacement fuse of the specified
rating. The outboard motor is
supplied with spare fuses in the
fuse holders.
1.
2.
3.
4.
09/06/22 18:12:29 31ZW5620_098
