Honda NC700S User Manual

78
Maintenance
Brakes
Checking Brake Fluid
1. Place your motorcycle in an upright
position on a firm, level surface.
2. Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LOWER level mark.
Check that the brake fluid reservoir
is horizontal and that the fluid level is
between the LOWER level and UPPER level
marks.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear. If the brake
pads are not worn, you most likely have a
leak. Have your motorcycle inspected by your
dealer.
Front
Rear
Front
Rear
Front brake
fluid reservoir
LOWER level mark
Rear brake fluid reservoir
LOWER level
mark
UPPER level
mark
12 NC700S (NM-1)-32MGS600.book 78 ページ ２０１２年４月１８日 水曜日 午後６時１７分

Honda NC700S Specifications

General

Bore x Stroke	73.0 mm x 80.0 mm
Compression Ratio	10.7:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Rear Brake	Single 240mm disc with single-piston caliper
Seat Height	790 mm
Fuel Capacity	14.1 liters
Max Power	35 kW (47 hp) @ 6, 250 rpm
Max Torque	60 Nm (44 lb-ft) @ 4, 750 rpm
Front Suspension Travel	120 mm
Rear Suspension Travel	120 mm
Ground Clearance	140 mm
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel twin
Front Suspension	41 mm telescopic fork
Rear Suspension	Pro-Link monoshock
Front Brake	Single 320 mm disc with 2-piston caliper
Front Tire	120/70ZR17
Rear Tire	160/60ZR17
Wheelbase	1, 525 mm
Width	760 mm
Height	1, 130 mm
