Honda NC700S User Manual

Brakes u Inspecting the Brake Pads
79
Maintenance
Inspecting the Brake Pads
Check the condition of the brake pad groove
wear indicators.
The pads need to be replaced if a
brake pad is worn to the indicator.
The pads need to be replaced if a
brake pad is worn to the indicator.
1. Inspect the brake pads from below
the brake caliper.
2. Inspect the brake pads from the
rear right of the motorcycle.
If necessary have the pads replaced by your
dealer.
Always replace both left and right brake pads
at the same time.
Front
Rear
Front
Rear
Front
Rear
Pad
Pad
Wear
indicator
Wear
indicator
Wear
indicator
Wear
indicator
Disc Disc
(NC700SA/SD)
(NC700S)
Disc
12 NC700S (NM-1)-32MGS600.book 79 ページ ２０１２年４月１８日 水曜日 午後６時１７分

Honda NC700S Specifications

General

Bore x Stroke	73.0 mm x 80.0 mm
Compression Ratio	10.7:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Rear Brake	Single 240mm disc with single-piston caliper
Seat Height	790 mm
Fuel Capacity	14.1 liters
Max Power	35 kW (47 hp) @ 6, 250 rpm
Max Torque	60 Nm (44 lb-ft) @ 4, 750 rpm
Front Suspension Travel	120 mm
Rear Suspension Travel	120 mm
Ground Clearance	140 mm
Engine Type	Liquid-cooled, 4-stroke, 8-valve, parallel twin
Front Suspension	41 mm telescopic fork
Rear Suspension	Pro-Link monoshock
Front Brake	Single 320 mm disc with 2-piston caliper
Front Tire	120/70ZR17
Rear Tire	160/60ZR17
Wheelbase	1, 525 mm
Width	760 mm
Height	1, 130 mm
