16
Quick Reference Guide
Heating and Cooling System
*
(P205)
● Toggle up and down the fan control switch to adjust the fan speed.
● Press the Mode button to select the vents air flows from.
● Toggle up and down the temperature control switch to adjust the temperature.
● Use the button for maximum cool setting.
● Press the button to turn the system on or off.
● Press the button to defrost the windshield.
Fan Control Switch
(Rear Window Defogger) Button
A/C (Air Conditioning) Button
Air flows from floor and
windshield defroster vents.
Air flows from floor vents.
Air flows from floor and
dashboard vents.
Air flows from dashboard
vents.
Button
(Recirculation) Button
Temperature Control Switch
(On/Off) Button
Mode Control Button
(Windshield Defroster) Button
