Clip
#
Removal
1.
Press down on the centre pin to release
the lock.
2.
Pull the clip out of the hole.
#
Installation
1.
Push the bottom of the centre pin.
2.
Insert the clip into the hole.
3.
Press down on the centre pin to lock the
clip.
20230106100355_32K2FD100_eng_BOOK Page 97 Friday, January 06 2023 10:07:46 JST
Removing & Installing Body Components u Clip
Maintenance
94
Centre pin
