GENERAL INFORMATION
1-15
REAR WHEEL/SUSPENSION
HYDRAULIC BRAKE
ANTI-LOCK BRAKE SYSTEM (ABS)
LIGHTS/METERS/SWITCHES
OTHER
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Swingarm mounting bolt 2 10 49 (5.0, 36)
Rear axle nut 1 16 118 (12.0, 87) U-nut.
Rear brake disc socket bolt 6 8 42 (4.3, 31) ALOC bolt.
Rear pulser ring torx bolt
(ABS type only)
4 5 8 (0.8, 5.9) ALOC bolt.
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Caliper bleed valve 3 8 5.4 (0.6, 4.0)
Pad pin 1 10 17 (1.7, 13)
Master cylinder reservoir cap
screw
4 4 1.5 (0.2, 1.1)
Brake hose oil bolt
STD type: 7 10 34 (3.5, 25)
ABS type: 6 10 34 (3.5, 25)
Brake pipe joint nut 1 10 14 (1.4, 10) Apply brake fluid to the
threads.
Brake lever pivot bolt 2 6 1 (0.1, 0.7)
Brake lever pivot nut 2 6 6 (0.6, 4.4)
Brake light switch screw 1 4 1.2 (0.1, 0.9)
Brake light/inhibitor switch screw 2 4 1.2 (0.1, 0.9)
Master cylinder holder bolt 4 6 12 (1.2, 9)
Caliper mounting bolt 4 8 30 (3.1, 22) ALOC bolt.
Front caliper pin bolt 1 8 22 (2.2, 16) Apply locking agent.
Front caliper bracket pin bolt 1 8 12 (1.2, 9) Apply locking agent.
Rear caliper bolt 1 8 22 (2.2, 16)
Rear caliper pin bolt 1 8 22 (2.2, 16) Apply locking agent.
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Brake pipe joint nut 6 10 14 (1.4, 10) Apply brake fluid to the
threads.
Sensor protector socket bolt 4 6 10 (1.0, 7) ALOC bolt.
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
License light unit screw 1 - 1.5 (0.2, 1.1)
Sidestand switch bolt 1 6 10 (1.0, 7)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Muffler protector special screw 9 5 5.2 (0.5, 3.8)
