Seat
#
Removal
1.
Remove the mounting bolt A and bolts B.
2.
Pull the seat back and up.
#
Installation
1.
Insert the tab into the frame cross member.
2.
Tighten the seat mounting bolts B.
Torque: 19 lbf·ft (26 N·m, 2.7 kgf·m)
3.
Tighten the seat mounting bolt A
securely.
Removing & Installing Body Components u Seat
Maintenance
52
Tab
Seat
Frame
cross
member
Seat mounting bolt A
Seat
mounting
bolts B
