Servicing Your Honda
154
Front Final Gear Oil
Refer to Safety Precautions on page 115.
1.
Park your Honda SXS on a firm, level surface. Shift the shift select
lever into the park (P) position.
2.
Remove the oil fill cap and O-ring.
3.
Make sure the oil level is at the lower edge of the oil fill inspection hole.
4.
Apply a thin coat of grease to a new O-ring, and insert it into the
oil fill cap groove.
5.
Install and tighten oil fill cap to the specified torque:
9 lbf·ft (12 N·m, 1.2 kgf·m)
Oil Recommendation
API classification
GL-5 except oils labeled as energy
conserving on the circular API
service label
type hypoid gear oil
viscosity (weight) SAE 80W-90
suggested oil Honda shaft drive oil or equivalent
Checking Oil
LEFT FRONT
lower edge of oil fill
inspection hole
oil fill cap/O-ring
