TRX400FGATRX400FA
(1) multi-function display
(2) drive mode indicator
(3) gear position indicator
(4) reverse indicator
(5) neutral indicator
(6) oil high temperature
indicator
(7) 4WD indicator
(8) oil change indicator
(9) speedometer
(10) odometer/tripmeter
(11) hourmeter/digital clock
(12) minute select button
minus button (TRX400FGA)
(13) hour select button
plus button (TRX400FGA)
(14) hourmeter/digital clock select
button
WP button (TRX400FGA)
(10)
(11)
(10),
(9)
(15) odometer/tripmeter select
button
mode select button
(TRX400FGA)
19
Multi-function Display
Indicators & Displays
Instruments & Controls
The multi-function display ( ) includes the following functions:
The digital clock will reset if the battery is disconnected.
1
Drive mode indicator
Gear position indicator
Oil change indicator
Speedometer
Odometer
Tripmeter
Digital clock
Hourmeter
