(1)
(1) seat lock lever
(2) seat
(3) studs
(4)
(2) (5)
(6)
(4) grommets
(5) front prongs
(6) hooks
(3)
88
Seat Removal
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Installation
Removal
Pull the seat ( ) up from the rear to remove the studs ( ) from the
grommets ( ).
Slide the seat back and up.
Insert the front prongs ( ) into the hooks ( ) on the frame and press
the studs into the grommets.
The seat must be removed for the air cleaner maintenance, and access to
the tool kit and owner’s manual.
Press down on the seat until it locks.
Pull the seat lock lever ( ) up below the rear end of the seat.
1.
2.
1.
2.
3.
4
3
56
1
77
2
07/04/04 11:22:17 31HP1640_097
