CONTROLS & FEATURES
CONTROLS
Fuel Valve Lever
The fuel valve opens and closes the
connection between the fuel tank and
the carburetor.
The fuel valve lever must be in the ON
position for the engine to run.
When the engine is not in use, leave
the fuel valve lever in the OFF position
to prevent carburetor flooding and to
reduce the possibility of fuel leakage.
Ignition Switch
The ignition switch controls the
ignition system.
The ignition switch must be in the ON
position for the engine to run.
Turning the ignition switch to the OFF
position stops the engine.
Choke Lever
The choke lever opens and closes the
choke valve in the carburetor.
The CLOSED position enriches the fuel
mixture for starting a cold engine.
The OPEN position provides the
correct fuel mixture for operation after
starting, and for restarting a warm
engine.
FUEL VALVE LEVER
ON
ON
OFF
OFF
IGNITION SWITCH
CHOKE LEVER
CLOSED
OPEN
