38
SERVICING YOUR PUMP
MUFFLER
SPARK ARRESTER
SPARK ARRESTER SCREEN
4 mm SCREW
5 mm SCREW (2)
5 mm SCREW (4)
SPARK ARRESTER
4mm
SCREW (2)
WT40X type
uses two 4 mm
screws.
MUFFLER PROTECTOR
WT30X and WT40X
Install the spark arrester, muffler protector, and muffler in the
reverse order of disassembly.
The spark arrester must be free of breaks and holes. Replace the
spark arrester if it is damaged.
Use a brush to remove carbon deposits from the spark arrester
screen. Be careful to avoid damaging the screen.
3.
4.
