CONTROLS & FEATURES
Throttle Lever
The throttle lever controls engine
speed.
Moving the throttle lever in the
directions shown makes the
engin
e run faster or slower.
Pump output is controlled by
adjusting the throttle lever. At
maximum
throttle position, the
pump will deliver the highest
output volume. Moving the
throttle lever toward the idle
position will decrease the output
volume of the pump.
Recoil Starter Grip
Pulling the starter grip operates the recoil starter
to crank the engine for
starting.
THROTTLE LEVER
MAXIMUM
THROTTLE
IDLE
STARTER GRIP
Direction to pull
31YF26100.book 10 ページ ２０１３年７月２３日 火曜日 午後４時５７分

Honda WX15 Specifications

General

Displacement	49.4 cc
Suction Head	8 m
Type	Centrifugal
Suction Head Lift	8 m
Fuel Type	Gasoline
Starting System	Recoil
Length	325 mm
Inlet/Outlet Diameter	1.5 in
Engine Type	4-stroke
Engine	GXH50
