Honda X-ADV 750 User Manual

Other Replacement
Replacing the
Honda SMART Key Battery
If the Honda SMART Key indicator flashes 5
times when the ignition switch is turned to
the (On) position, or the operating range
becomes unstable, replace the battery as
soon as possible.
We recommend to see your dealer for this
service.
Battery type: CR2032
1. Remove the upper case by inserting a
coin or a flat head screwdriver covered
with a protective cloth into the slit.
u Wrap a coin or a screwdriver with a
protective cloth to prevent scratching
the Honda SMART Key.
u Do not touch the circuit or terminal.
This may cause problems.
u Be careful to avoid scratching the
waterproof covering or allowing dust
to enter.
u
Do not forcibly dismantle the Honda
SMART Key body.
Maintenance
115
Continued

Honda X-ADV 750 Specifications

General

Displacement	745 cc
Max Torque	69 Nm @ 4, 750 rpm
Transmission	6-speed Dual Clutch Transmission (DCT)
Seat Height	820 mm
Curb Weight	236 kg
Front Tire	120/70 R17
Rear Tire	160/60 R15
Compression Ratio	10.7:1
Final Drive	Chain
Fuel System	PGM-FI electronic fuel injection
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Max Power Output	43.1 kW @ 6, 750 rpm
Fuel Tank Capacity	13.2 liters
Front Suspension	41mm USD fork
Rear Suspension	Pro-Link monoshock, 150 mm travel
Front Brake	Dual 296 mm discs
Rear Brake	240mm single disc
Bore x Stroke	77 mm x 80 mm
Wheelbase	1, 580 mm
