Honda XR650L 2019 User Manual

Importance of Maintenance ........................... P. 31
Maintenance Schedule
..................................... P. 33
Maintenance Record......................................... P. 36
Maintenance Fundamentals ...........................P. 37
Removing & Installing Body Components..P. 50
Battery.................................................................... P. 50
Seat ......................................................................... P. 51
Shroud....................................................................P. 52
Left Side Cover..................................................... P. 53
Right Side Cover.................................................. P. 54
Spark Plug ........................................................... P. 55
Spark Arrester/Muffler.....................................P. 57
Engine Oil ............................................................ P. 58
Engine Idle Speed.............................................. P. 63
Air Cleaner........................................................... P. 64
Brakes................................................................... P. 65
Side Stand ........................................................... P. 68
Drive Chain..........................................................P. 69
Wheels..................................................................P. 74
Clutch ...................................................................P. 75
Throttle ................................................................ P. 78
Other Adjustments............................................ P. 79
Adjusting the Headlight Aim ............................ P. 79
Adjusting the Front Suspension....................... P. 80
Adjusting the Rear Suspension ........................ P. 82
20180910132946_31MGW6700_enu_BOOK Page 33 Monday, September 10 2018 13:35:28 JST
Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully
before attempting any maintenance. Refer to “Specifications” for service data.
An optional larger tool kit may be available.
Check with your Honda dealer's parts department.
Maintenance

Honda XR650L 2019 Specifications

General

Engine Type	644cc air-cooled dry-sump single-cylinder four-stroke
Bore and Stroke	100.0mm x 82.0mm
Compression Ratio	8.3:1
Transmission	Five-speed
Front Brake	Single 256mm disc with twin-piston caliper
Rear Brake	Single 220mm disc with single-piston caliper
Front Tire	3.00-21
Rear Tire	4.60-18
Wheelbase	57.3 inches
Seat Height	37.0 inches
Ground Clearance	13.0 inches
Rake	28.0 degrees
Valve Train	SOHC; four-valve
Final Drive	#520 chain; 15T/45T
Front Suspension	43mm telescopic fork; 11.6 inches travel
Curb Weight	346 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
Fuel Capacity	2.8 gallons, including 0.6-gallon reserve
Rear Suspension	Pro-Link Showa single shock with spring preload, compression and rebound damping adjustability; 11.0 inches travel
