BENDIX/KING KCS 55/55A
Page 1-2
©Honeywell International Inc. Do not print without express permission of Honeywell Rev 11, Apr/2007
The tumble detect version, (KG 102A, P/N 060-0015-02), while in slaved gyro mode will automat-
ically switch the system to fast slave mode when rates exceed approximately 25 degrees per sec-
ond. Once the system display (KI 525/525A) matches earth’s magnetic field +/- 2 degrees, the
system will revert back to slow slave mode.
Stabilized heading information is supplied to the KI 525/525A by the KG 102/102A. When in the
slaved gyro mode this heading signal, which may vary at rates up to 30 degrees/second, is
summed with the normal slaving signal from the KMT 112 to provide the final drive signal for the
heading display.
When the system is in the free gyro mode the heading signal from the KG102/102A is the only
input to the heading display drive. While in the free gyro mode the pilot may command changes
in the displayed heading by means of depressing the clockwise or counterclockwise push buttons
on the KA 51/51A (toggle switches on the KA 51B).
1.3 TECHNICAL CHARACTERISTICS
1.3.1 KCS 55/55A
1.3.2 KI 525/525A
SPECIFICATION CHARACTERISTIC
TSO COMPLIANCE: TSO C6c
RTCA DO-138 Environmental Categories
KI 525/525A, versions 00-03 & 10-12
DAMAAAXXXXXX
KI 525A versions 04-08 DAPAAAXXXXXX
KA 51/51A: DAMAAAXXXXXX
KA 51B: (see section 1.3.6)
KG 102, KA 52; KA 57: BAJAAAXXXXXX
KG 102A: BA/JN/AAAXXXXXX
KMT 112: BA/SV/AAAXXXXXX
SYSTEM ACCURACY: Accurate to within 2° of local magnetic heading.
POWER REQUIREMENTS:
14VDC 15.8 max., 3.23 A
11.0 min.
28VDC 31.6 max., 1.73 A
22.0 min.
5VDC .4 A
SLAVING RATE:
Normal: 3 degrees per minute
Fast: 180 degrees per minute
SLAVING SENSITIVITY: and
±0.5
o
when in a field strength of Hx = 0.18 gauss
Hz = 0.54 gauss.
WARM-UP TIME:
Varies from 1 min. at +55
o
C to 5 min. at -46
o
C.
RELEASED FOR THE EXCLUSIVE USE BY: AIRCRAFT ELECTRONICS ASSOCIATION
UP536434
