Table 1-4 KA 51B Version Chart
1.4.5 KA 52 AUTOPILOT ADAPTER
The KA 52 Autopilot Adapter is an optional remote mounted device that converts the DC heading
and course datum signals from the KI 525/525A Indicator into two separate AC signals compatible
with certain autopilot systems. PN 071-1055-00 is the standard version. PN 071-1055-01 is avail-
able when 115 V 400 Hz ref. is needed by Radar for Stabilization.
1.4.6 KA 57 AUTOPILOT ADAPTER
The KA 57 Autopilot Adapter (PN 071-0017-00) is an optional remote mounted device that con-
verts the DC heading and course datum signals from the KI 525/525A Indicator into a single, swit-
chable AC output signal compatible with certain autopilot systems.
1.5 INSTALLATION KITS
See figure 1-1 for crimping, insertion, and extraction tools.
PN BEZEL LIGHTING FACEPLATE
071-1242-00 BLACK 14 V VERTICAL
071-1242-01 BLACK 28 V VERTICAL
071-1242-02 GRAY 28 V VERTICAL
071-1242-03 BLACK 5 V RED VERTICAL
071-1242-04 BLACK 28 V RED VERTICAL
071-1242-05 BLACK 14 V HORIZONTAL
071-1242-06 BLACK 28 V HORIZONTAL
071-1242-07 GRAY 5 V HORIZONTAL
071-1242-08 GRAY 5 V VERTICAL
071-1242-09 GRAY 28 V HORIZONTAL
071-1242-10 BLACK 5 V VERTICAL
071-1242-11 BLACK 5 V HORIZONTAL
071-1242-13 GRAY 5 V VERTICAL
071-1242-14 GRAY 5 V HORIZONTAL
