Honeywell CADVR-1004-WD-M User Manual

5
●…
Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC
COM to upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
●…PTZ control
Support PTZ decoder via RS485.
Support various decode protocols to allow the PTZ to control the speed dome.
Intelligent operation
Mouse operation function
●…
In the menu, support copy and paste setup function
●…UPnP
It is to establish the mapping relationship between the LAN and the WAN via the UPnP
protocol.
Slight function differences may be found due to different series.
DIGITAL VIDEO RECORDER
SPECIFICATION (1SATA Mini Series)
Model
CADVR-1004WD-M
CADVR-1008WD-M
Video
Video Input
4CH, 1.0Vp-p, 75Ω
8CH, 1.0Vp-p, 75Ω
Video Standard
NTSC/PAL
Video Output
CVBS/VGA/HDMI
VGA Output
1024*768, 1280*1024, 1440*900,720P,1080P
Spot Output
NO
Image & storage
Resolution
4CH WD1 record &2CH WD1 real time
playback
8CH WD1 record & 1CH WD1 real time
playback
Audio
Input & Output
4CH RCA Input / 1CH RCA Output
2CH RCA I Input / 1CH RCA Output
Voice Talk
No
Recording
Compression Format
H.264 VBR / CBR
Compression
WD1 Real Time
Recording Mode
Manual/alarm/motion detection/timing
Motion Detection
Each Channel Area Selectable(Sensitivity Adjustable)
Data Authentication
NO Watermarking
Display
Multiscreen Display
1 / 4 Windows
1 / 4 / 8 / 9 Windows
Playback
Playback
4CH WD1 Recording+2ch WD1 Playback
8CH WD1 Recording+1ch WD1 Playback
Playback Mode
Normal Playback, Various playback speed (Forward, Backward, Step)
Search Mode
Date/Time
Alarm

Honeywell CADVR-1004-WD-M Specifications

General

Brand	Honeywell
Model	CADVR-1004-WD-M
Category	DVR
Language	English
