10
USE & OPERATION
FILLING WATER
FILLING WATER ( MANUALLY)
Unplug from power when refilling.
CAUTION
To refill the water tank, pull out the Water/Ice Fill Door located
on the top side of your cooler (refer to page 7) and fill water till
the Max, as indicated on the Water Level Indicator. Do not fill
water above the Max water level mark.
For better cooling performance, we suggest putting ice cubes
inside the ice compartment located on the top side of your
cooler (refer to page 7).
Water Inlet
Water Fill Door
Ice Loading
Compartment
Water can be filled into the air cooler by:
Continuous water supply (Auto Refill)
Connect a garden hose to the continuous water supply inlet.
Water / Ice compartment (Manual Refill)
Water / ice can be put into the tank though the top opening.
There is a hole for water to flow into the tank.
