8 Replacement Kit Instruction 43-DR-33-87 3/05
Mother board
J8
1
1
J2
7 cond. cable
J13
1
1J1
4 cond. cable
Chassis
ground
1
J14
Main
board
J4
1
J2
Alarm/digital
inputs
J1 1
34 cond.
ribbon cable
30755119-001
J8
Chart Plate
Display
board
30755064-001, 20 conductor ribbon cable
4 conductor cable
4 conductor cable
4 conductor cable
Chassis ground
Pen 2
Motor
Chart motor
J7 J5
Pen #1 drive
Pen #2 drive
Chart drive
1
11
Main transformer
9 position keyboard cable
J2
J3
2 wire
purple pair
2 wire
orange pair
Second
input
1
J3
2 wire
light
2 wire
gray pair
Light line to J1
J11
J3
1
30754982-001
30755062-001
Pen 1
Motor
Figure 3 DR4500 Classic Recorder (DR4501,DR4502) Internal Cabling Data
