F50E DUCT MOUNTED ELECTRONIC AIR CLEANER
68-0072—5
22
Nominal Return Air Opening
Description 16 x 25 in. (406 x 635 mm) 20 x 25 in. (508 x 635 mm)
Ionizer Wires (multiples of 5) 136434BA 136434AA
Remote Mount Kit 136377A (1) 136377A (1)
Remote Mount Base 136377 (1) 136377 (1)
Conduit Assembly (10 ft.) 136376A (1) 136376A (1)
Cabinet Knockout Plug 136743 (1) 136743 (1)
Mounting Screws 136375 (6) 136375 (6)
Quick-Connect Terminal 111690 (2) 111690 (2)
Spring Leaf Contact 136529 (1) 136529 (1)
Sail Switch S688A1007 (1) S688A1007 (1)
Replacement Sail 123773A (1) 123773A (1)
2-Stage EAC Cell for F50 with Collector Clip FC37A1247 (2) FC37A1239 (2)
(#) = Qty Required Per Unit
Nominal Return Air Opening
No. Description 16 x 25 in. (406 x 635 mm) 20 x 25 in. (508 x 635 mm)
1 Access Door includes #2 136393AL (1) 136392AQ (1)
2 Test Button Assembly 137980A (1) 137980A (1)
3 Electronic Cell FC37A1130 (2) FC37A1064 (2)
4 Cell Handle 137266 (2) 137266 (2)
5 Prefilter 203371 (2) 203372 (2)
6 Cell Key 136518 (1) 136518 (1)
7 Contact Panel Assembly 136399A (1) 136399A (1)
8 Junction Box Assembly 136394B (1) 136394B (1)
9 Junction Box Cover 136386 (1) 136386 (1)
10 Power Box Assembly With W8600E capability
120V, 60 Hz 200583B (1) 200583A (1)
11 Power Supply, 120V, 60 Hz 203327F 203327D
12 FC37A Bag Assembly for cell repair.
Contains 2 Connector Clips, 1 Terminal Board
and Instructions.
4074EHG 4074EHG
(#) = Qty Required Per Unit
PARTS LIST
Parts and Accessories Not Illustrated
Note: Click for earlier F50E manual with a parts drawing that shows more replaceable parts
