THE SOLID STATE PERFORMANCE INDICATOR
This electronic air cleaner is equipped
with a special solid state circuit that
operates the optional W8600E Solid
State Performance Indicator (see
photo). The W8600E Indicator must be
ordered separately.
The W8600E Indicator is designed to
mount next to your thermostat, or in any
convenient visible area (such as a utility
room) where it can be seen as it
monitors the air cleaner's performance.
The three light-emitting diodes (LEDs)
on the W8600E are labeled ON, WASH
and CHECK.
• The ON LED is lit during normal air cleaning operation. The
system fan is also on when the air cleaner is running.
• If excessive dirt has accumulated on the air cleaner cell(s),
the WASH LED will light to alert you that a cell and prefilter
wash is past due.
• Extreme dirt loading (beyond that required to activate the
WASH LED), electronic malfunction, or other equipment
problems will cause the CHECK LED to light.
69-0376—4 2
