69-0419—2
STEP 2
It is very important that the electronic cell(s) be
properly replaced:
a. Electrical contact board
must face
the power
supply contacts.
b. Airflow arrows on the cell(s) must point into
the air duct.
c. Hook the cell(s) on the metal hooks and
rotate into the air cleaner.
d. Rotate the cell latch to secure the cell(s).
CELL LATCH
M9676A
12
