F57A,B FLUSH-MOUNTED COMMERCIAL ELECTRONIC AIR CLEANER
68-0083-7 Revised 11-07
17
P3
P4
P1
P2

1
RED IONIZER
BLACK COLLECTOR
1 POWER SUPPLY. PROVIDE DISCONNECT 
 MEANS AND OVERLOAD PROTECTION 
 AS REQUIRED.

2 LEFT CELL AND CONTACT BOARD ON
 TWO-CELL AIR CLEANER ONLY.

3 INTERLOCK SAFETY SWITCH.



M10652

POWER
SUPPLY

2
BLACK
RED
TEST
BUTTON
CONTACT

BOARD
BROWN
VIOLET
BLUE
RED
ON
HI
MED
LO
HI
MED
LO
OFF
FAN
MOTOR

3
PERFORMANCE
SWITCH
BLACK
BLACK
WHITE
ORANGEBLACK
L1
(HOT)
L2
GROUND


PUSH BUTTONS WIRING TERMINALS
ON-OFF/3-SPEED FAN SWITCH
CHECK
(RED)
WASH
(YELLOW)
WHITE
RED
WHITE
RED
WHITE
RED
ON
(YELLOW)
J5
Fig. 18. F57A,B 120V model electrical schematic.
