Honeywell HCW 80 User Manual

Installation
4
1
1
2
Fig. 2: Opening the housing cover
1
2
Fig. 3: Removing the terminal covers
> 7 mm Æ
< 7 mm Æ
Fig. 4: Connecting the relay module to the power supply
max. 2.5 mm
2
Fig. 5: Wiring the terminal
Caution
Incorrect wiring!
► Install in accordance with local wiring
regulations.
► Observe ambient temperature and
current limits (see HC60NG wiring
label).

Honeywell HCW 80 Specifications

General

Brand	Honeywell
Model	HCW 80
Category	Thermostat
Language	English
