HE220A,B AND HE260A,B BYPASS FLOW-THROUGH HUMIDIFIER
68-0191—3 2
ORDERING INFORMATION
When purchasing replacement and modernization products from your TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalog or price sheets for complete ordering number.
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Home and Building Control Sales Office (check white pages of your phone directory).
2. Home and Building Control Customer Logistics
Honeywell Inc., 1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386 (612) 951-1000
In Canada—Honeywell Limited/Honeywell Limitée, 155 Gordon Baker Road, North York, Ontario M2H 3N7.
International Sales and Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France,
Germany, Japan, Mexico, Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
SPECIFICATIONS
Capacity:
At 120°F (49°C) plenum temperature and 0.20 static
pressure drop across supply and return:
HE220A,B: 12 gallons per day (gpd) or 46 liters per day
(lpd).
HE260A,B: 17 gallons per day (gpd) or 65 liters per day
(lpd).
Humidified Area:
See Table 1.
Electrical Ratings:
24 Vac, 60 Hz, 0.5A.
Humidifier Pad Dimensions:
See Table 2.
Plenum Opening Dimensions (Height x Width):
See Table 3.
Summer Shut-off Damper Dimensions (Height x Width):
See Table 4.
Bypass Duct Opening (Diameter):
6 in. (152 mm).
Drain Connection:
1/2 in. (13 mm) I.D. plastic hose connected directly to drain
fitting on unit.
Dimensions:
Refer to Fig. 1 and 2.
Table 1. Size Of Area That Can Be Humidified.
HE220 Area (Up To) HE260 Area (Up To)
House Description Air Changes Per Hour Sq ft Sq m Sq ft Sq m
Loose Two 750 70 1,000 93
Average One 1,500 140 2,000 186
Tight One-half 3,000 280 4,000 372
Model Height Width Depth
HE220 9-13/16 (249) 9-1/2 (241) 1-1/2 (38)
HE260 13 (330) 10 (254) 1-1/2 (38)
Model Height Width
HE220 9-7/16 (241) 9-5/16 (238)
HE260 12-5/8 (321) 9-3/4 (248)
Model Height Width
HE220 9-3/16 (234) 8-7/8 (226)
HE260 12-3/8 (314) 9-5/16 (236)
Table 2. Dimensions Of Humidifier Pads In In. (mm).
Table 3. Dimensions Of Plenum Opening In In. (mm).
Table 4. Dimensions Of Summer Shut-off Damper
In In. (mm).
