3EN
INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Local Air Conditioner. Please call Customer Support if you have any difficulties or queries
regarding these installation procedures.
Installation Kit:
Installation Steps:
Exhaust Hose Connector, Exhaust Hose and window bracket panel adapter are pre-assembled
inside the package.
1.
1. Window Bracket Kit (1 Set) 4. Exhaust Hose (1 Piece)
2. Window Bracket Panel Adapter (1 Piece) 5. Drain Tube (1 Piece)
3. Exhaust Hose Connector (1 Piece) 6. Butterfly Screws (1 Piece)
4 5 6
1 3
x1
x1 x1 x1
x1 x1
2
Hose:
Length: 10.23'' to 47'' (26cm to 120cm)
To Next Page
