6
7
Label the wires
Use the provided stickers to label
the wires connected to the following
terminals:
G
R
W or W1 (not in all systems)
Y or Y1
Note: If multiple wires are connected
to a terminal, only label the wires
running to your thermostat.
*
EXAMPLE
C
W or W1
Y or Y1
R
G
W2
R
G
W
Y
*
