7
8
Disconnect the labeled wires
Be sure you have taken a photo of
your wires before disconnecting.
Disconnect only the wires that you
just labeled. Do not disconnect any
unlabeled wires.
*
If unlabeled wires disconnect, replace
immediately.
*
Note: You may need a screwdriver to
release wires from terminals.
EXAMPLE
C
W or W1
Y or Y1
R
G
W2
R
G
W
Y
*
