Honeywell HON 372 - Spare Parts Drawings HON 372 DN 80 through DN 150

Item Part no.
no. Denomination Number W Materials DN 80 DN 100 DN 150
370.20 p.11
9 Lock washer 3 St 14122 14122 14122
10 Hex nut 3 St 5559 5559 5559
11 Locking screw 3 St 12473 12473 12473
22 Dowel pin 2 St 17269 17269 17269
23 Cable box 1 24099 24099 24099
24 Proximity switch 1 24160 24160 24160
25 Relay 230 V, 1 channels 1 24402 24402 24402
25 Relay 230 V, 2 channels 1 24403 24403 24403
26 Sealing cap 1 St 10633 10633 10634
27 O ring 1 W KG 21250 21250 21252
30 Sealing ring 1 W LM 518017 518017 518017
31 Screwed connection 1 St 530047 530047 530047
32 Sealing ring 1 W LM 518017 518017 518017
33 Sealing cap 1 St 10363 10363 10363
60 Hex screw 4 St 10630 10630
61 Lock washer 4 St 14121 14121
62 O ring 1 W KG 20428 20428
63 Hex screw 8 St 10630 510001 510113
64 Lock washer 8 St 14121 14119 14116
65 SSV cover, optional:
65 SSV cover 2 GGG 15057016 15058013 15059014
65 SSV cover GS 15057017 15058014 15059015
65 SSV cover GS 15057018 15058015 15059016
66 O ring 1 W KG 21263 21266 520082
67 Body, optional:
67 Body with SSV; PN16 1 GGG 15057101 15058101 15059001
67 Body with SSV; PN16 1 GS 15057103 15058103 15059005
67 Body with SSV; PN16 1 GS 15057105 15058105 15059009
67 Body with SSV; class 150 1 GGG 15057102 15058102 15059002
67 Body with SSV; class 150 1 GS 15057104 15058104 15059006
67 Body with SSV; class 150 1 GS 15057106 15058106 15059010
67 Body without SSV; PN16 1 GGG 15057151 15058151 15059003
67 Body without SSV; PN16 1 GS 15057153 15058153 15059007
67 Body without SSV; PN16 1 GS 15057155 15058155 15059011
67 Body without SSV; class 150 1 GGG 15057152 15058152 15059004
67 Body without SSV; class 150 1 GS 15057154 15058154 15059008
67 Body without SSV; class 150 1 GS 15057156 15058156 15059012
3.2.2 Spare parts drawings HON 372 DN 80 through DN 150
