Power-Limited Wiring Requirements Installation
HPFF8(E)/HPFF8CM(E) NAC Expander — P/N 53499:B4 10/1/2018 27
TB1 on 24 VDC circuit board
L1
Ground
L2
Ground Stud
Wire Nut
Line Neutral Ground
Figure 2.19 Nonpower-Limited Wiring Example: EQBB-D4 AC Wiring (Expanded)
Ring Terminal
