ASSEMBLY INSTRUCTIONS
A. BASE ASSEMBLY
• Remove the L shaped bolt (counter clockwise) and
washer from the bottom of the silver fan pole. (Fig. 3).
Fig.3
Fig.5
Fig.6
Fig.4
Base
Control
Panel
Rear Grille
Mounting Nut
Motor
Assembly
Oscillation
Knob
Remote
Control
Twist and Lock Height
Adjustment
Blade Knob
Rear Grille
Fan Blade
Clips
Metal Fan Pole
Thumb Screw
L Shaped Bolt
Front Grille
B. SECURING THE FAN TO THE BASE
• Extend the silver pole to its full length, place the
fan pole into the base. (Fig. 4).
• Align the pole in the base using tabs as a guide.
• Gently place base on its side. (Fig. 5).
• Insert and tighten the L shaped bolt and washer
on the bottom of the fan base. (Fig. 6).
• Tighten by turning clockwise. (Fig. 6).
