6
M7261,M7272,M7274,M7281,M7282,M7284,M7285,M7286,M7294
INSTALLATION
Fig. 3—Mounting the motor with an adapter bracket.
M452D
EQUIPMENT
BASE
ADAPTER
BRACKET
STANDARD
BOLTS (4)
MOTOR
BOLTS
PROVIDED (4)
WIRING
BOX
POWER
END
POWER
END
NON-SPRING RETURN
SPRING RETURN
1 #12 OR 1/4" ZINC PLATED
MACHINE SCREWS OR BOLTS
1
POWER END
POWER END
POWER END
